Payment & Shipping Terms:
|Material:||Stainless Steel||Color:||Blue Or Customized|
Mertal oil and gas pipelines dedicated bending machine is the use of a number of new technologies: 1 on a roll by reverse rolling deformation method to eliminate the process of deflection of the roller 2 on both ends of the press-roller using multiple sets of cylinder pressure. , fixed cylinder piston rod, cylinder lifting seat and drive the roll movements, effective use of space, increasing material utilization, greatly reducing the overall weight of the equipment, 3. products discharged from inside the material out of the stent material, the stent without turning inverted reset, enhanced security, 4. product discharge using automatic cylinder to drive (the company another patent technology), suitable for assembly line.
Bending small-caliber special thick-walled steel making is that I learn from foreign technology developed by the company's patented products. Our company is the introduction of foreign technology products, combined with the characteristics of the product, developed from its superior performance in domestic same products, with efficient, low-energy, easy operation and other features of the device has a unique advantage in the following aspects: 1), the minimum thickness of rolling up to 12.5 times the diameter of the cold roll; 2), the use of pressure beam on the elimination of anti-distortion technology combined volume. deflection when the system rolls on small-diameter pipe, products roundness; 3), coiling barrel rolling products straightness control within 1/2000; 4), the lower roll center distance is adjustable, can be pre bend, can also be rolled; 5), the use of automatic feeding device, effectively prevent the occurrence of the wrong side of .6), rolling process is calculated by the computer-controlled rolling process automation.
With the use of a sewing machine, after bending machine can be composed of welded pipe production line. The company provides technical support for the entire line.
|MCLW11G oil and gas transmission pipe bending machine technical parameters|
|Model||Bending thickness(mm)||Max plate width(mm)||Diameter of
|Main motor power(kw)|
