The second generation of hydraulic shears.
Rack turret with the overall welded structure, the vibration to eliminate stress, to maintain good accuracy.
The use of advanced integrated hydraulic system reliability.
Three-point support rolling guide to eliminate the bearing clearance, improve cut quality.
Blade gap adjustment handwheel rapid, accurate and convenient.
Rectangular blades with four cutting edges, long service life.
Adjustable shearing angle to reduce deformation of the sheet.
Upper blade holder within the structure are easy blanking, improve the accuracy of parts.
Shearing in sections function.
After maneuvering gauge, digital display.
|
Machine type |
thickness can be cut |
After the block range, the main motor power |
trips |
After the block range |
shear angle |
the main motor power |
|
mm |
mm |
min -1 |
mm |
° |
kw |
|
|
6×2500 |
6 |
2500 |
20-25 |
600 |
0.5-1.5 |
7.5 |
|
6×3200 |
6 |
3200 |
16-25 |
600 |
0.5-1.5 |
7.5 |
|
6×4000 |
6 |
4000 |
14-25 |
600 |
0.5-1.5 |
7.5 |
|
6×5000 |
6 |
5000 |
10-15 |
800 |
0.5-1.5 |
7.5 |
|
6×6000 |
6 |
6000 |
10-15 |
800 |
0.5-1.5 |
11 |
|
8×2500 |
8 |
2500 |
18-25 |
600 |
0.5-1.5 |
11 |
|
8×3200 |
8 |
3200 |
16-25 |
600 |
0.5-1.5 |
11 |
|
8×4000 |
8 |
4000 |
12-25 |
600 |
0.5-1.5 |
11 |
|
12×2500 |
12 |
2500 |
12-20 |
600 |
0.5-2 |
15 |
|
12×3200 |
12 |
3200 |
12-20 |
600 |
0.5-2 |
15 |
|
12×4000 |
12 |
4000 |
12-20 |
600 |
0.5-2 |
15 |
|
16×2500 |
16 |
2500 |
10-15 |
800 |
0.5-2.5 |
18.5 |
|
16×3200 |
16 |
3200 |
10-15 |
800 |
0.5-2.5 |
18.5 |
|
16×4000 |
16 |
4000 |
8-15 |
800 |
0.5-2.5 |
18.5 |
|
20×2500 |
20 |
2500 |
8-12 |
800 |
0.5-2.5 |
30 |
|
20×4000 |
20 |
4000 |
8-12 |
800 |
0.5-2.5 |
30 |
|
25×2500 |
25 |
2500 |
6-10 |
800 |
0.5-3.5 |
37 |
|
25×3200 |
25 |
3200 |
6-10 |
800 |
0.5-3.5 |
37 |
|
25×4000 |
25 |
4000 |
6-10 |
1000 |
0.5-3.5 |
37 |
|
32×2500 |
32 |
2500 |
6-8 |
1000 |
0.5-3.5 |
45 |
|
32×3200 |
32 |
3200 |
6-8 |
1000 |
0.5-3.5 |
45 |
|
40×2500 |
40 |
2500 |
4-8 |
1000 |
0.5-3.5 |
75 |
|
40×3200 |
40 |
3200 |
4-8 |
1000 |
0.5-3.5 |
75 |
