Marine three-roller plate, pressure head bending machines, hydraulic machine,plate rolling machine for shipbuilding

Marine three-roller plate, pressure head bending machines, hydraulic machine,plate rolling machine for shipbuilding

China Marine three-roller plate, pressure head bending machines, hydraulic machine,plate rolling machine for shipbuilding supplier
Marine three-roller plate, pressure head bending machines, hydraulic machine,plate rolling machine for shipbuilding supplier Marine three-roller plate, pressure head bending machines, hydraulic machine,plate rolling machine for shipbuilding supplier

Large Image :  Marine three-roller plate, pressure head bending machines, hydraulic machine,plate rolling machine for shipbuilding

Product Details:

Place of Origin: JiangSu
Brand Name: China Mertal
Certification: ISO and CE
Model Number: MCLW

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: $5000-$50000
Packaging Details: Customized or naked
Delivery Time: It's up to machine's capacity
Payment Terms: T/T
Supply Ability: 20 sets/month
Contact Now
Detailed Product Description
Condition: New Color: Red Blue Or Customized
Brand: Mertal Material: Carbon Steel

Marine machine

It is mainly used to rolling of ship hull, arc plate and slot type bulkhead. According to the customer's requirements, can be designed into symmetric and asymmetric type three roller plate bending machine, roll on the upper part is equipped with rigid girder, lower on the back and forward between roller and supporting roller have multiple sets of roller, to improve the rigidity of the roll up and down, all three roll drive.

Marine machine type can be divided into the following kinds:

A) on the symmetric mode: work roll can be done on the vertical lifting movement, under the two work roll position relatively unchanged.

B) the overall level of the lower roll mode: the work roll on vertical lifting movement, under the direction of the overall level of the work roll translational motion.

C) under the roller respectively levels mode: work roll on vertical lifting movement, work roll under horizontal translational motion, respectively.

D) on roller universal: work roll in vertical lifting movement, and translational motion in a horizontal direction, under the two work roll position relatively unchanged.

Marine three-roller plate, pressure head bending machines, hydraulic machine,plate rolling machine for shipbuildingMarine three-roller plate, pressure head bending machines, hydraulic machine,plate rolling machine for shipbuilding


.

Marine three-roller plate, pressure head bending machines, hydraulic machine,plate rolling machine for shipbuilding


MCLW11C Three roller plate rolling machine for shipping technical parameters
Model Max bending thickness(mm) Max plate width(mm) Yielding Linit(Mpa) Main motor power(kw)
MCLW11C-20X8000 20 8000 245 45
MCLW11C-25X12000 25 12000 245 55
MCLW11C-30X12000 30 12000 245 75
MCLW11C-30X16000 30 16000 245 110
MCLW11C-40X18000 40 18000 245 2x75
MCLW11C-40X21000 40 21000 245 2x75
