Metal Plate Atuomaitic CNC Press Brake Machinery High Efficiency and High Precision

Good quality Oil And Gas Transmission Pipe Rolling Machine for sales
Good quality Oil And Gas Transmission Pipe Rolling Machine for sales
I'm Online Chat Now

Metal Plate Atuomaitic CNC Press Brake Machinery High Efficiency and High Precision

China Metal Plate Atuomaitic CNC Press Brake Machinery High Efficiency and High Precision supplier
Metal Plate Atuomaitic CNC Press Brake Machinery High Efficiency and High Precision supplier Metal Plate Atuomaitic CNC Press Brake Machinery High Efficiency and High Precision supplier Metal Plate Atuomaitic CNC Press Brake Machinery High Efficiency and High Precision supplier

Large Image :  Metal Plate Atuomaitic CNC Press Brake Machinery High Efficiency and High Precision

Product Details:

Place of Origin: JiangSu
Brand Name: China Mertal
Certification: ISO and CE
Model Number: MCLW

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: $5000-$50000
Packaging Details: Customized or naked
Delivery Time: It's up to machine's capacity
Payment Terms: T/T
Supply Ability: 20 sets/month
Contact Now
Detailed Product Description
Condition: New Color: Red Or Customized
Brand: MERTAL Material: Carbon Steel



Detailed Product Description



Color: Blue Or Customized Controler: ESTUN E21
Voltage: 380V/3P/50HZ Or Customized After-sales Service Provided: Engineers Available To Service Overseas
Port: Shanghai Port,China Shipment: By Sea









Hydraulic Metal Plate CNC Press Brake  High precision Metal Machinery for Sale



Main functions:



● All steel welded structure, stress relieved for high rigidity and stability
● Torsion shaft forced synchronization of mechanical limit stopper balance,with high precision
● Integrated hyrdraulic transmission system,large range of speed regulation thanks to transmission of
the sliding block, stable and reliable performance
● Rear stopper and the sliding block have electrical adjustment for the stroke,with manual fine tuning,and digital indication
● Adjustment mechanism of sliding block independent from oil cylinder assembly to enhance sealing effect of upper punch
retainer is fitted with tilting warp offset mechanism
● For bending machine from 250Tup synchronization mechanism of mechanical or electrical hydraulic transmission is fitted,
lower working table is fitted with warp offset mechanism
● Multi machine combined operation is possible



Standard accessories:


The back and side safety guard;
Chinese good gear pump, Amerisia OMG valve, Japanese sealing rings;
E10 LCD Digital, normal screw, CE electric;
Back gauge with function of swift off when the back guard is opened;
Electric back gauge
Machine has been improved according to European customer suggestions;


Main specification:





Model No.

Normal

Pressure

(KN)

Length

Of table

(mm)



Distance

Between

Housing

(mm)

Throat

Depth

(mm)



Stroke

(mm)

Open

Height

(mm)

Motor

Power

(Kw)

Net

Weight

(Kg)

Size(LxWxH )(Cm)

WC67Y-63/2500

630

2500

2000

320

150

400

5.5

5000

286x165x235

WC67Y-63/3200

630

3200

2700

320

150

400

5.5

5500

380x165x245

WC67Y-80/2500

800

2500

2000

320

150

400

5.5

5500

286x165x235

WC67Y-80/3200

800

3200

2700

320

150

400

7.5

6500

380x165x245

WC67Y-100/3200

1000

3200

2700

400

180

460

7.5

7500

381x175x248

WC67Y-125/3200

1250

3200

2700

400

180

460

7.5

8200

382x180x250

WC67Y-125/4000

1250

4000

3200

400

180

460

7.5

9000

460x180x256

WC67Y-160/3200

1600

3200

2700

400

180

460

11

10800

383x203x256

WC67Y-160/4000

1600

4000

3200

400

180

460

11

11500

461x203x270

WC67Y-200/3200

2000

3200

2700

400

180

460

11

12500

390x205x256

WC67Y-200/4000

2000

4000

3200

400

180

480

11

13800

462x205x275

WC67Y-200/6000

2000

6000

4800

400

180

480

11

18500

605x230x320

WC67Y-250/3200

2500

3200

2700

400

200

480

15

15000

390x210x265

WC67Y-250/4000

2500

4000

3200

400

200

560

15

16000

462x210x280

WC67Y-250/5000

2500

5000

4000

400

250

560

15

18500

509x257x310

WC67Y-250/6000

2500

6000

4800

400

250

560

15

20000

608x257x330

WC67Y-300/4000

3000

4000

3200

400

250

560

22

19000

408x230x320

WC67Y-300/5000

3000

5000

4000

400

250

560

22

23000

510x240x360

WC67Y-300/6000

3000

6000

4800

400

250

630

22

27000

615x250x360

WC67Y-400/4000

4000

4000

3200

400

320

630

30

27000

410x275x360

WC67Y-400/5000

4000

5000

4000

400

320

630

30

32000

510x275x380

WC67Y-400/6000

4000

6000

4800

400

320

630

30

38000

615x275x400

WC67Y-500/4000

5000

4000

3200

400

320

630

37

40000

415x350x398

WC67Y-500/5000

5000

5000

4000

400

320

630

37

45000

515x360x470

WC67Y-500/6000

5000

6000

4800

400

320

630

37

45000

615x362x520

WC67Y-600/5000

6000

5000

4000

500

320

630

45

50000

515x380x520

WC67Y-600/6000

6000

6000

4800

500

320

630

45

68000

615x444x550

WC67Y-800/5000

8000

5000

4000

500

350

800

55

75000

516x450x530

WC67Y-800/6000

8000

6000

4800

500

350

800

55

85000

620x492x580

WC67Y-1000/6000

10000

6000

4800

500

400

800

55

10500

650x494x630




Metal Plate Atuomaitic CNC Press Brake Machinery High Efficiency and High PrecisionMetal Plate Atuomaitic CNC Press Brake Machinery High Efficiency and High PrecisionMetal Plate Atuomaitic CNC Press Brake Machinery High Efficiency and High Precision
