Plate leveling machine Small four heavy roller precision leveling machine, leveling machine

Plate leveling machine Small four heavy roller precision leveling machine, leveling machine

China Plate leveling machine Small four heavy roller precision leveling machine, leveling machine supplier
Plate leveling machine Small four heavy roller precision leveling machine, leveling machine supplier Plate leveling machine Small four heavy roller precision leveling machine, leveling machine supplier Plate leveling machine Small four heavy roller precision leveling machine, leveling machine supplier

Large Image :  Plate leveling machine Small four heavy roller precision leveling machine, leveling machine

Product Details:

Place of Origin: JiangSu
Brand Name: China Mertal
Certification: ISO and CE
Model Number: MCLW

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: $5000-$50000
Packaging Details: Customized or naked
Delivery Time: It's up to machine's capacity
Payment Terms: T/T
Supply Ability: 20 sets/month
Contact Now
Detailed Product Description
Condition: New Color: Customized
HS Code: 816229 Brand: Mertal
Material: Carbon Steel



MCLW43 PLATE LEVLING MACHINE

MCLW43-series palte leveling macine is for roll metal sheet leveling special equipment,often by power,host,and electeical controls.

FEATURES

MCLW43-series plate leveling machine is dedicated to the cold metal sheet,take advantage of a number of roller works,so that the sheet metal works between the upper and lowerrollers repeated,deformation and relief stress,changing avariety of original curvature gradually becomes single curvature (bauschinger effect) to achieve the objective of the plain. As the precision request,in the upper and lower roller lateral,set rigid support roller (wheel),constitute a quadruple-group or six-group roll structure.

ADVANTAGES

When metal through the leveling machine ,can significantly improve their flat state,improving the quality of the worfkpiece.Independently,for single sheets of plain;also can configure open-book,cited material,cutting,and stracking behind configuration and online agencies,among others,by controlling the system into a complete production line.

Technical parameters for Leveling machine
Model Max Leveling thickness(mm) Max Leveling width(mm) Min Leveling thicknessr(mm) Yielding Linit(Mpa) Main motor power(Kw)
MCLW43-3x1000 3 1000 0.8 360 15
MCLW43-3x1600 3 1600 0.8 18.5
MCLW43-6x2000 6 2000 1.5 37
MCLW43-10x2000 10 2000 2.5 45
MCLW43-12x1200 12 1200 3 30
MCLW43-12x2000 12 2000 3 55
MCLW43-12x2500 12 2500 4 2x30
MCLW43-16x2000 16 2000 4 2x30
MCLW43-16x2500 16 2500 4 2x30
MCLW43-16x3200 16 3200 4 2x45
MCLW43-20x2500 20 2500 5 2x45
MCLW43-25x2500 25 2500 6 2x45
MCLW43-30x3000 30 3000 6 2x45
MCLW43-32x2000 32 2000 8 2x45
MCLW43-40x2500 40 2500 10 2x55
MCLW43-50x3200 50 3200 12 2x55




Plate leveling machine Small four heavy roller precision leveling machine, leveling machinePlate leveling machine Small four heavy roller precision leveling machine, leveling machinePlate leveling machine Small four heavy roller precision leveling machine, leveling machineMCLW43 PLATE LEVLING MACHINE
