Plate bending machine MCLW12CNC-50*3200 Plate Rolling Machine with CE Standard

China Plate bending machine MCLW12CNC-50*3200 Plate Rolling Machine with CE Standard supplier
Plate bending machine MCLW12CNC-50*3200 Plate Rolling Machine with CE Standard supplier Plate bending machine MCLW12CNC-50*3200 Plate Rolling Machine with CE Standard supplier Plate bending machine MCLW12CNC-50*3200 Plate Rolling Machine with CE Standard supplier Plate bending machine MCLW12CNC-50*3200 Plate Rolling Machine with CE Standard supplier

Large Image :  Plate bending machine MCLW12CNC-50*3200 Plate Rolling Machine with CE Standard

Product Details:

Place of Origin: JiangSu
Brand Name: China Mertal
Certification: ISO and CE
Model Number: MCLW

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: $5000-$50000
Packaging Details: Customized or naked
Delivery Time: It's up to machine's capacity
Payment Terms: T/T
Supply Ability: 20 sets/month
Contact Now
Detailed Product Description
Condition: New Color: Customized
Material: Stainless Steel Brand: Mertal
HS Code: 846229

MCLW12HXNC Four rollers Bending  plate rolling machine with CE standard, automatic rolling machine/Гидравлический вальцовочный станок



Main feaure



The machine adopts the four roller structure with the upper and lower roller as the main drive, providing the plates

bending with torque through the engagement between the gear of the moderator and the gear of the

upper roller.

The lower roller moves  vertically and imposes a force on the piston via. the hydraulic cylinder.

Outer rollers are arranged on both sides of the two inner lower roller. and make inclining movement along

the guide rail, and are provided with drive through the lead screw nut and worm gear.

The advantage of this is that the preliminary bending and rolling of the top ends of the plates be done on

 the same machine.



Main configuration:


- PLC OMRON brand, Japan
- Touch screen is from famous brand
- Hydraulic pump is from China famous brand
- Hydraulic valve is from YUKEN brand, Japan
- Sealings are from NOK brand, Japan
- Main electric components are from SIEMENS
- Motors are from SIEMENS
- 4 roller material is 42CrMo
- With Cone-bending function
- With Pre-bending function
- NC control to show the side roller position, easy operation.

Four roller plate rolling machine

Superiority and some features usually only in large size plate rolling machine:

fully hydraulic-driven (as opposed to the usual manual and mechanical movement)

multiple independent hydraulic motor (as opposed to only one set of electric motors, reduction unit and gear)

automatic hydraulic line speed compensation (as distinct from inefficient clutch)

clamping pressure control (as opposed to holding without control)

Following users apply to use the machine

first use of the user, because this is one of the most easy-to-operate machine

operators lack of inspection requires high productivity,

increase profitability requires high accuracy,

improving quality want only one operator, reducing labor costs

due to the large size of the Board, production of high-or for security reasons require handling device

want to use CNC operations, reduce operational personnel action levels think factor

Plate bending machine MCLW12CNC-50*3200 Plate Rolling Machine with CE Standard





Plate bending machine MCLW12CNC-50*3200 Plate Rolling Machine with CE StandardPlate bending machine MCLW12CNC-50*3200 Plate Rolling Machine with CE StandardPlate bending machine MCLW12CNC-50*3200 Plate Rolling Machine with CE StandardPlate bending machine MCLW12CNC-50*3200 Plate Rolling Machine with CE Standard

MCLW12HXNC Four roller plate rolling machine technical parameters
    Model Max pre-bending thickness(mm) Max bending thickness(mm) Diameter of upper roller(mm) Max plate width(mm) Main motor power(kw)
MCLW12-3x1500 2 3 135 1500 2.2
MCLW12-5x1500 3 5 190 1500 4
MCLW12-10x2000 8 10 240 2000 11
MCLW12-10x2500 8 10 260 2500 15
MCLW12-12x2000 10 12 260 2000 15
MCLW12-15x2000 12 15 265 2000 18.5
MCLW12-15x2500 12 15 280 2500 22
MCLW12-20x2000 16 20 300 2000 30
MCLW12-20x2500 16 20 340 2500 30
MCLW12-25x2500 20 25 390 2500 30+7.5
MCLW12-25x3000 20 25 420 3000 37+7.5
MCLW12-30x2500 25 30 420 2500 37+7.5
MCLW12-30x3000 25 30 460 3000 45
MCLW12-35x2500 30 35 460 2500 45
MCLW12-35x3000 30 35 510 3000 55
MCLW12-35x3500 30 35 550 3500 55
MCLW12-40x2500 35 40 510 2500 55
MCLW12-40x3000 35 40 550 3000 55
MCLW12-40x3500 35 40 560 3500 55+7.5
MCLW12-50x2500 45 50 560 2500 55+7.5
MCLW12-50x3000 45 50 605 3000 55
MCLW12-50x3500 45 50 640 3500 75
MCLW12-60x3000 50 60 670 3000 108.5
MCLW12-60x3500 50 60 700 3500 75
MCLW12-70x3000 65 70 720 3000 90
MCLW12-70x3500 65 70 760 3500 90
MCLW12-80x3000 70 80 780 3000 90
MCLW12-80x3500 70 80 840 3500 55*2
MCLW12-80x4000 70 80 870 4000 55*2
MCLW12-90x3000 80 90 810 3000 75*2
MCLW12-90x3500 80 90 890 3500 75*2
MCLW12-90x4000 80 90 925 4000 75*2
MCLW12-100x3000 85 100 850 3000 45*4
MCLW12-100x3500 85 100 925 3500 45*4
MCLW12-100x4000 85 100 960 4000 45*4
MCLW12-120x3000 100 120 940 3000 55*4
MCLW12-120x3500 100 120 980 3500 55*4
MCLW12-120x4000 100 120 1020 4000 55*4
MCLW12-140x3000 115 140 1000 3000 75*4
MCLW12-160x3500 130 160 1220 3500 90*4
MCLW12-180x3000 150 180 1280 3500 55*8
MCLW12-200x4000 160 200 1500 4000 75*8
