Mechanical three roller plate bending machine,, plate rolling machine export
-
-
Large Image :
Mechanical three roller plate bending machine,, plate rolling machine export
|
Product Details:
Place of Origin: |
JiangSu |
Brand Name: |
China Mertal |
Certification: |
ISO and CE |
Model Number: |
MCLW |
Payment & Shipping Terms:
Minimum Order Quantity: |
1 piece |
Price: |
$5000-$50000 |
Packaging Details: |
Customized or naked |
Delivery Time: |
It's up to machine's capacity |
Payment Terms: |
T/T |
Supply Ability: |
20 sets/month |
|
Detailed Product Description
Mechanical Three Roller Symmetrical Bending Machine
Mechanical Three Roller Symmetrical Bending Machine Features: The machine structure type symmetric three roller, roller in two central symmetrical position under the roller moves vertically through the screw nut worm drive and get the two lower rollers rotational movement, through the output gear reducer with lower tooth engagement provide torque roll sheet. the machine is compact structure, easy operation and maintenance. the machine requires the use of other equipment to complete pre-bending.
MCLW11 Mechanical 3-roller plate rolling machine technical parameters |
Model |
Max bending thickness(mm) |
Max plate width(mm) |
Diameter of upper roller(mm) |
Main motor power(kw) |
MCLW11-4x1500 |
4 |
1500 |
150 |
3 |
MCLW11-6x1500 |
6 |
1500 |
160 |
4 |
MCLW11-6x2000 |
6 |
2000 |
170 |
5.5 |
MCLW11-6x3200 |
6 |
3200 |
220 |
7.5 |
MCLW11-8x2000 |
8 |
2000 |
185 |
5.5 |
MCLW11-8x2500 |
8 |
2500 |
240 |
7.5 |
MCLW11-12x2000 |
12 |
2000 |
240 |
7.5 |
MCLW11-12x2500 |
12 |
2500 |
260 |
7.5 |
MCLW11-12x3000 |
12 |
3000 |
280 |
11 |
MCLW11-16x2000 |
16 |
2000 |
260 |
7.5 |
MCLW11-16x2500 |
16 |
2500 |
280 |
11 |
MCLW11-16x3200 |
16 |
3200 |
340 |
15 |
MCLW11-20x2000 |
20 |
2000 |
280 |
15 |
MCLW11-20x2500 |
20 |
2500 |
340 |
15 |
MCLW11-25x2000 |
25 |
2000 |
330 |
15 |
MCLW11-25x2500 |
25 |
2500 |
370 |
22 |
MCLW11-30x2500 |
30 |
2500 |
390 |
30 |
MCLW11-30x3000 |
30 |
3000 |
450 |
37 |
