Large Image :  Pipe welding machine Pipe Station Automatic Welding System

Product Details:

Place of Origin: JiangSu
Brand Name: China Mertal
Certification: ISO and CE
Model Number: MCLW

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: $5000-$50000
Packaging Details: Customized or naked
Delivery Time: It's up to machine's capacity
Payment Terms: T/T
Supply Ability: 20 sets/month
Contact Now
Detailed Product Description
Condition: New Material: Stainless Steel
Color: Blue HS Code: 846229
Brand: Mertal

Pipe Station Automatic Welding System

Unigue pipe root pass welding procedure
Patent open headstock design



Brief

The pipe welding tool series system is used for welding pipe to pipe, pipe to flange, pipe to elbow, pipe to tee etc. It can realize the pipe automatic centering, automatic (manual) clamping, and stable rotation by means of patented headstock technology. It can be used for automatic processing of root pass, filling pass, and cap pass, in cooperation with arc voltage controller (AVC), monitor and so on.



Features

Pipe welding machine Pipe Station Automatic Welding System Easy load and unload by open design;
Pipe welding machine Pipe Station Automatic Welding System Avoid axial jumping during the rotation;
Pipe welding machine Pipe Station Automatic Welding System Avoid radial jumping during the rotation
Pipe welding machine Pipe Station Automatic Welding System Motor-driven three-jaws clamping, automatic centering to minimized labor intensity;
Pipe welding machine Pipe Station Automatic Welding System AC servo motor driven, large speed adjustment, quick response, high accurate;
Pipe welding machine Pipe Station Automatic Welding System Gear/sprocket drive for high transmission efficiency, big load ability to adapt to poor working conditions.

Specification

Item KB230 KB370 KB500 KB630 KB760
Rotation Speed (Servo control) 3.7r/min 4.3r/min 3.5r/min 2r/min 2.26r/min
Maximum Torque 2500N.m 2900N.m 7000N.m 20000N.m 20000N.m
Welding Diameter φ34~φ230mm φ114~φ370mm φ219~φ500mm φ60~φ630mm φ219~φ760mm
Payload 550kg 1300kg 3000kg 5000kg 5000kg
Motor Power 1.3KW 1.3KW 3.0KW 4.4KW 4.4KW
Rotation Center Height 600mm 780mm 950mm 1190mm 1280mm
Dimension 550×440×830 774×500×1135 1000×630×1420 1750×1200×1945 2100×1090×2140
Clamp Method motor-driven motor-driven motor-driven servo motor driven
manual



Pipe welding machine Pipe Station Automatic Welding SystemPipe welding machine Pipe Station Automatic Welding SystemPipe welding machine Pipe Station Automatic Welding SystemPipe welding machine Pipe Station Automatic Welding System
